Product Introduction
The ENPI1100-T4 Ethernet Adapter is a low-cost, low-power, 1GbE PCIe low-profile adapter that supports dual-port Gigabit Ethernet. It also provides the ability to optimize network resource allocation for virtualized applications, which is suitable for big data analysis, machine learning, and virtualization environment applications.
Product Features
-
Widely AdaptableFull platform adaptation, after extensive actual scene verification, the product has strong compatibility, and has obtained VMware IOVP, TOS, and major domestic and foreign cloud vendors certification, meeting the adaptation needs of all walks of life -
Green and Energy-SavingAdopting advanced hardware architecture and refined power consumption design, the typical power consumption of 3.9W provides 1Gbps high-speed transmission, providing energy-saving and efficient network card products for data centers and enterprise-level applications -
Ultimate PerformanceSupports SR-IOV, WOL and NFV functions, PCIe network card optimized for server virtualization
Product Parameters
Attribute
inagile ENPI1100-T4 1G network adapter
Specification
PCIe Half-Height NIC
Controller Chips
Intel i350 Gigabit Ethernet Controller
Host Interface
PCIe v2.1 (2.5GT/s and 5GT/s) x4/x2/x1
Port Interface
Four-port Gigabit Ethernet
Port Connectors
4 x RJ45 for 1000BASE-T, 100BASE-TX and 10BASE-T
Power Consumption
3.9W
Authentication
International CB, EU CE, United States FCC, United States UL, Korea KC
Working Environment
Operating temperature: 0°C to 55°C
Storage temperature: -40°C to +70°C
