Product Introduction
The NS8600/8500 G2 are high-performance enterprise-grade NVMe SSDs. Equipped with a PCIe Gen4x4 enterprise-class controller and 112L 3D eTLC NAND solution, they comply with the NVMe 1.4 protocol, catering to read/write-intensive and read-intensive applications respectively. Leveraging self-developed firmware architecture and hardware design, the NS8600/8500 G2 feature high performance, durability, and reliability, ensuring high-speed stable read/write IOPS, bandwidth, and extremely low jitter latency. They are applicable to system layers, performance layers, and storage layers for scenarios such as databases, cloud services, distributed storage, and big data.
Product Features
-
Extreme Energy Efficiency：The Suzhou Yingji NS8600/8500 G2 enterprise-grade NVMe SSDs adopt an independently developed advanced firmware architecture and multi-level fine-grained power consumption design, delivering high read/write bandwidths of 7GB/s and 5GB/s. They provide low-power and high-efficiency storage solutions for data centers and enterprise applications. -
Extreme Reliability：The Suzhou Yingji NS8600/8500 G2 enterprise-grade NVMe SSDs integrate an innovatively designed NAND characteristic algorithm model, significantly improving NAND Flash P/E cycles and extending the SSD lifespan. With a measured MTBF exceeding 2.6 million hours, they are supported by robust fault-tolerance and error-correction mechanisms, end-to-end data protection across the entire path, variable stripe RAID, and hardware-software collaborative power failure protection—offering multi-layered and three-dimensional safeguards for data security and reliability. -
Extreme Stability：The Suzhou Yingji NS8600/8500 G2 enterprise-grade NVMe SSDs feature extremely low I/O jitter, with 4K random read/write IOPS consistency exceeding 85%. They also deliver ultra-low latencies of 75/11μs, ensuring excellent QoS (Quality of Service).
Product Parameters
Name
NS8500/8600G2
Type
2.5-inch NVMe SSD
Form Factor
U.2
Interface
PCIe Gen4 x4
Capacity
1.92TB;3.84TB;7.68TB;15.36TB;1.6TB;3.2TB;6.4TB;12.8TB
128KB sequential read
7000 MB/s
128KB sequential write
2625MB/s;4500 MB/s;5000 MB/s;5000 MB/s;2625 MB/s;4500 MB/s;5000 MB/s;5000 MB/s
4KB sustained random read
780K;1450K;1600K;1600K;780K;1450K;1600K;1600K
4KB sustained random write
126K;200K;210K;210K;200K;360K;400K;400K
The Average Read Latency Is 4 KB
75μs;75μs;75μs;76μs;75μs;75μs;75μs;76μs
The Average Write Latency of 4 KB
11μs;11μs;11μs;12μs;11μs;11μs;11μs;12μs
Years of quality assurance
5 years
Drive Writes Per Day（DWPD）
1time;1time;1time;1time;3time;3time;3time;3time
Maximum Power Consumption
25W
Standby Power Consumption
9.5W
Mean Time Between Failures（MTBF）
2.60 million hours
Uncorrectable Bit Error Rate（UBER）
≤ 10-17
Data retention
3 months (≤ 40 ° C)
Hot Pluggable
Yes
Power Loss Protection
Yes
Product Certification
RoHS、CE、FCC、UL、etc.
Other Functions
NDU , atomic write, boot disk, multi-level power management, SMART , in-band and out-of-band management, temperature control, firmware authentication, etc.
