Stability and Reliability:Equipped with built-in NAND characteristic algorithms, supporting static or dynamic wear leveling. The measured MTBF exceeds the specified standard, reaching 2.8 million hours. It provides end-to-end data protection across the entire path, variable stripe RAID, and a power failure protection solution through hardware-software collaboration, ensuring comprehensive protection for stable and reliable business operations. -
Security and Control:Utilizes controlled NAND Flash particles, controller, and DRAM particles, along with self-developed firmware and hardware. It supports multiple security features such as lossless performance encryption to safeguard data privacy with security and control. -
High Efficiency and Energy Saving:Adopts an independently developed advanced firmware architecture and multi-level fine-grained power consumption design, providing ultra-high read/write bandwidth of up to 7.4GB/s and 6.1GB/s with a low power consumption of only 3-16W, meeting the requirements of low-power application scenarios. -
Comprehensive Functions:Supports the Verify function to strictly maintain data quality, a pre-reading function for silky-smooth business experience with ultra-low latency, WRR differentiated IO allocation, and NDU (Non-Disruptive Update) for online upgrades without service interruption.
|
Name |
NS6500G2 |
NS6600G2 |
||||
|
Type |
2.5 inch NVMe SSD |
|||||
|
Form Factor |
U.2 |
|||||
|
Interface |
PCIe Gen4 x4 |
|||||
|
Capacity |
1.92TB |
3.84TB |
7.68TB |
1.6TB |
3.2TB |
6.4TB |
|
128KB sequential read |
7400 MB/s |
7400 MB/s |
7400 MB/s |
7400 MB/s |
7400 MB/s |
7400 MB/s |
|
128KB sequential write |
2800 MB/s |
5300 MB/s |
6100 MB/s |
2800 MB/s |
5300 MB/s |
6100 MB/s |
|
4KB sustained random read |
850K IOPs |
1100K IOPs |
1200K IOPs |
850K IOPs |
1100K IOPs |
1200K IOPs |
|
4KB sustained random write |
120K IOPs |
200K IOPs |
240K IOPs |
200K IOPs |
400K IOPs |
440K IOPs |
|
4KB sustained random write |
70μs |
70μs |
71μs |
70μs |
70μs |
71μs |
|
4KB average write latency |
9μs |
9μs |
9μs |
9μs |
9μs |
9μs |
|
4KB random read IOPs consistency |
99% |
|||||
|
4KB random read IOPs consistency |
99% |
|||||
|
Years of quality assurance |
5 years |
|||||
|
Drive Writes Per Day（DWPD） |
1 |
3 |
||||
|
Mean Time Between Failures（MTBF） |
2.50 million hours |
|||||
|
Uncorrectable Bit Error Rate（UBER） |
≤ 10-17 |
|||||
|
Data retention |
3 months (≤ 40 ° C) |
|||||
|
Hot Pluggable |
Yes |
|||||
|
Power Loss Protection |
Yes |
|||||
|
Product Certification |
RoHS、CE、FCC、UL、etc. |
|||||
|
Other Functions |
NDU, atomic write, multi-level power management, SMART , in-band and out-of-band management, TRIM, self-encryption, Telemetry, write zero, write uncorrectable, Device Self-Test (DST), sanitize, WRR , etc. |
|||||
