TS6000G1

Stability & Reliability、Security & Control、Efficiency & Energy Saving、Comprehensive Functionality

TS6000G1

Enterprise-Class SATA SSD

Product Introduction

The TS6000G1 is an industry-leading enterprise-class controller with single-port SATA III and 8 NAND CH x 8 CE. It supports 4K LDPC ECC technology, which significantly reduces data error rates and enhances data persistence. Meanwhile, it supports advanced functions such as Smart Cache technology, multi-level power management, and overheat protection. With excellent read/write performance, remarkable stability, reliability, and durability, it becomes an ideal storage medium.

Product Features

Product Parameters

Name	TS6000G1
Type	2.5 inch SATA SSD
Form Factor	U.2
Interface	SATA III
Capacity	480GB	960GB	1.92TB	3.84TB
128KB sequential read	540 MB/s	540 MB/s	540 MB/s	540 MB/s
128KB sequential write	520 MB/s	520 MB/s	520 MB/s	520 MB/s
4KB sustained random read	93K IOPs	93K IOPs	93K IOPs	93K IOPs
4KB sustained random write	26K IOPs	35K IOPs	50K IOPs	50K IOPs
4KB sustained random write	110μs	110μs	110μs	110μs
4KB average write latency	35μs	35μs	35μs	35μs
4KB random read IOPs consistency	95%
4KB random read IOPs consistency	90%
Years of quality assurance	5 years
Drive Writes Per Day（DWPD）	1
Mean Time Between Failures（MTBF）	2.0 million hours
Uncorrectable Bit Error Rate（UBER）	≤ 10-17
Data retention	3 months (≤ 40 ° C)
Hot Pluggable	Yes
Power Loss Protection	Yes
Product Certification	RoHS、CE、FCC、UL、etc.
Other Functions	NDU, boot disk, multi-level power management, SMART , secure erase, etc.
